Parameters |
| Performance Parameters | |||
| Picture Sensor | SXGA-W | ||
| Scan Pattern | Automatic Scan | ||
| Capacity | 1D | EAN-8, EAN-13, EAN-13, UPC-A, UPC-E, Code 32, Code 39, Code 93, Code 128, Codebar, Industrial 2 of 5, Interleave 2 of 5, MSI, GSI | |
| 2D | PDF417, MicroPFD417, DataMatrix, QR code, Aztec | ||
| System Compatibility | Linux, Android, IOS, Windows XP, Windows 7, Windows 8, Windows 10 | ||
|
Depth of Field |
Tested Code | Minimum | Maximum |
| Code 39–5mil | 1cm | 9cm | |
| DM–12mil | 1cm | 19cm | |
| EAN-13 | 1cm | 21cm | |
| 16 mil QR | 1cm | 25cm | |
| 7 Mil PDF417 | 1cm | 11cm | |
| Lamp-house Type | White LED | ||
| Keyboard support | Multilanguage keyboard | ||
| Decode Accuracy |
Code 39 4mil | ||
| Code Available | 1D and 2D Codes printing on Paper or Film or Screen | ||
| Scanning Speed | 2300 Times/Second | ||
| Symbol Contrast | 20% | ||
| Secondary development | No support | ||
| Barcode output editing | Support adding prefix and suffixes | ||
| Scanning Angle | Horizontal:72º Vertical:82º Rotated:360z | ||
| Human Computer Interaction | |||
| Indicator light | Red and blue LED, Red light mains tips, blue light decoding flicker tips | ||
| Buzzer | Start Tips, Decoding tips | ||
| Button | Switch scanning mode | ||
| Program Update | Support Client Side Update | ||
| Environment Parameters | |||
| Drop | Design to withstand 1.5 m drops to concrete 5 times | ||
| Environmental Sealing | IP54 | ||
| Working/Conserve temperature | (-20) ~ 55ºC / (-20) ~ 60ºC | ||
| Working/Conserve Humidity | 5-95% Non-Condensed | ||
| Enviroment Light | 0 – 120000LUX | ||
| Physical Parameters | |||
| Net Weight | 445g | ||
| Host Size (L*W*H) | 124mm*110mm*160mm | ||
| Interface | USB, Serial port | ||
| Certification | CE, FCC, ROHS | ||
